Cell phone motor starter controller @ mobile starter

[mobitechwireless]

CELL PHONE MOTOR STARTER CONTROLLER​

Cell phone motor starter controller is a device to switch on/off and monitor pump set from remote location with the help of mobile phone as remote control.

View attachment 4203
​

Specifications

Model : WMC
Dimension : 4” (L) x 1.5” (W) x 6” (H)
Weight : 0.75kg
Input Voltage : 180V-280V (1 phase) & 350V-450V (3 phase)
Power consumption : 5W
Network Support : Quad Band GSM 850/900/1800/1900 – All mobile operators
Connectors : Plug-n-play connectors
Wiring kit : 0.5sq.mm 9 core cable
Battery: 3.7v
Enclosure : Metallic
Antenna : High Gain external antenna (3m)
Certification : ETDC

Features

1. Switch ON/OFF pumpset through “MISSED CALL” or SMS

2. Flexible wiring set with plug and play connectors

3. Suitable for 1/2HP to 500HP electric motors(1Phase & 3Phase)

4. Suitable for all type of old button starter’s like L&T, BCH, Oil starter’s and panel board

5. Control through 10 mobile numbers

6. Multi-language SMS support

7. Monitor LOG report through web server

8. Inbuilt

a. Single phase preventer
b. Low voltage preventer
c. Auto-starter(delay)
d. Preset timer
e. Dry run preventer

8. Manual ON/OFF intimation

9. Theft proof

Pack Contains

GSM Control Unit -1 No

1. External antenna with 10feet cable – 1 No

2. 9 Core flexible wiring kit 1metre – 1 No

3. 500mA 3cm Fuse -3 Nos

4. Dry Run Sensor -1 No(Extra Chargeable)

5. Battery-1 No

6. User manual with wiring diagram

Installation Photo's

View attachment 4204
Mobile Starter Model: WMC

View attachment 4205


Model: WMC fitted in 3HP Pump set

​

For More Information

Mobitech Wireless Solution
1/4 Vengamedu, Erode Road, Perundurai,
Erode Dt, Tamilnadu.
Mob: +91 9865666700 | +91 9943430000



[murjani]

What is the cost?
Raaj



[vg marati]

pls send em the costings per motor



[mobitechwireless]

Dear Sir:

Price of full kit cell phone motor starter controller is Rs. 7750.00

Pack Contains:

1. GSM Control Unit -1 No

2. External antenna with 10feet cable – 1 No

3. 9 Core flexible wiring kit 1metre – 1 No

4. 500mA 3cm Fuse -3 Nos

5. Dry Run Sensor -1 No(Extra Chargeable)

6. Battery-1 No

7. User manual with wiring diagram

Please contact Mobitech Wireless Solution @ 8012330000 | sales@mobitechwireless.in
